Versatile 3-in-1 servo feeder for coil widths to 400 mm — integrated decoiler, straightener, and NC feeder.
The LNCF4 3-in-1 decoiler, straightener, and servo feeder is designed for coil material 0.5–4.5 mm thick and up to 400 mm wide. This 3-in-1 is an integrated solution for coil feed in press-room operations, combining decoiling, straightening, and precise servo feeding in one compact unit.
The LNCF4 opens various coil sizes, the upper roller adjusts by digital watch, coil width is set by a double handle wheel with precise screw, and pass line height is adjusted by a motor-driven lifter. Suitable for medium-sized progressive stamping dies.
3-in-1: decoiler + straightener + servo feeder in one unit
Upper roller adjustment by digital watch
Coil width adjusted by double handle wheel with precise screw
Pass line adjusted by motor-driven lifter
Servo motor feed with digital pitch setting
Handles up to 4.5 mm thick material
For Metals: carbon steel, stainless steel, aluminium, copper
| Material thickness | 0.5–4.5 mm |
| Material width | 50–400 mm |
| Coil weight (max) | 500 kg |
| Feed length | 1–9,999.9 mm |
| Feed accuracy | ±0.1 mm |
| Straightening rollers | 9 rolls |
| Sync method | Cam signal / encoder |
| Control | NC servo + HMI |
* Specifications are indicative. Contact KingJime engineers for custom configurations and exact parameters.
