High-load 3-in-1 servo feeder for coil up to 6 mm thick — servo motor drive with touchscreen controls.
The TNCF6 3-in-1 is designed for heavy-gauge coil material up to 6 mm thick and 600 mm wide. It combines decoiling, straightening, and NC servo feeding in a single robust unit, suitable for demanding press-room environments processing thick carbon steel, stainless steel, and aluminium.
The TNCF6 features a heavy-duty straightener with increased roller diameter, a powerful servo motor drive, and an HMI touchscreen for digital parameter setting. Its solid frame construction handles the higher forces involved in thick-material straightening and feeding.
3-in-1: decoiler + straightener + servo feeder in one unit
Handles up to 6 mm thick material
Heavy-duty straightener with larger roller diameter
Powerful servo motor drive for thick material feeding
Digital HMI touchscreen control with recipe storage
Pass line height adjustable by motorised lifter
For Metals: carbon steel, stainless steel, aluminium, high-strength steel
| Material thickness | 0.5–6.0 mm |
| Material width | 100–600 mm |
| Coil weight (max) | 800 kg |
| Feed length | 1–9,999.9 mm |
| Feed accuracy | ±0.1 mm |
| Straightening rollers | 9 rolls (HD) |
| Sync method | Cam signal / encoder |
| Control | NC servo + HMI |
* Specifications are indicative. Contact KingJime engineers for custom configurations and exact parameters.
